- Overall Span 15'
- Span Between Wheel Centers 14' 1"
- Clear Span 13' 6"
- Overall Height Under Beam (Min. 12' 4") (Max. 15' 10")
- Overall Height (Min. 13' 2") (Max. 16' 8")
- Beam Size S10X25.4#, Beam Flange Width 4-5/8"
- Tread Width 6' 6", Wheel Dia. 8'
- Crane Height Adjustments: Adjusting in 6-inch increments, height adjustment kits use spring-loaded steel locking pins that automatically engage when height positioning holes are reached; adjust heights for specific lifts, uneven floors, or to move through doorways
- Adjustable Spans: Standard on aluminum cranes, adjustable spans are optional on steel cranes; adjustable spans allow the crane to be shortened for transport down narrow aisles
- Heavy-Duty Casters: Four-position, swivel-lock casters with moldon polyurethane wheels provide excellent floor protection
