- Overall Span 35'
- Span Between Wheel Centers 34' 1"
- Clear Span 33' 8"
- Overall Height Under Beam 10' 0"
- Overall Height 11' 6"
- Beam Size W18X55#, Beam Flange Width 7-1/2"
- Tread Width 6' 6", Wheel Dia. 8'
- Crane Height Adjustments: Adjusting in 6-inch increments, height adjustment kits use spring-loaded steel locking pins that automatically engage when height positioning holes are reached; adjust heights for specific lifts, uneven floors, or to move through doorways
- Adjustable Spans: Standard on aluminum cranes, adjustable spans are optional on steel cranes; adjustable spans allow the crane to be shortened for transport down narrow aisles
- Heavy-Duty Casters: Four-position, swivel-lock casters with moldon polyurethane wheels provide excellent floor protection
