- Overall Span 12'
- Span Between Wheel Centers 11' 3"
- Clear Span 10' 11"
- Overall Height Under Beam 10' 0"
- Overall Height 10' 6"
- Beam Size S6X12.5#, Beam Flange Width 3-3/8"
- Tread Width 5' 5", Wheel Dia. 6'
- Crane Height Adjustments: Adjusting in 6-inch increments, height adjustment kits use spring-loaded steel locking pins that automatically engage when height positioning holes are reached; adjust heights for specific lifts, uneven floors, or to move through doorways
- Adjustable Spans: Standard on aluminum cranes, adjustable spans are optional on steel cranes; adjustable spans allow the crane to be shortened for transport down narrow aisles
- Heavy-Duty Casters: Four-position, swivel-lock casters with moldon polyurethane wheels provide excellent floor protection
