- Overall Span 8'
- Span Between Wheel Centers 7' 3"
- Clear Span 6' 11"
- Overall Height Under Beam (Min. 9' 8") (Max. 12' 8")
- Overall Height (Min. 7' 8") (Max. 10' 8")
- Beam Size S6X12.5#, Beam Flange Width 3-3/8"
- Tread Width 5' 5", Wheel Dia. 6'
- Crane Height Adjustments: Adjusting in 6-inch increments, height adjustment kits use spring-loaded steel locking pins that automatically engage when height positioning holes are reached; adjust heights for specific lifts, uneven floors, or to move through doorways
- Adjustable Spans: Standard on aluminum cranes, adjustable spans are optional on steel cranes; adjustable spans allow the crane to be shortened for transport down narrow aisles
- Heavy-Duty Casters: Four-position, swivel-lock casters with moldon polyurethane wheels provide excellent floor protection
